Pour X-Press 3000 Enclosed Automated Wax Melting & Filling System
PRIMO melting and AutoShot automated filling in a fully enclosed stainless mobile platform. Configure melter size, hose length and 3 dosing ranges. Starting price $13,995 USD. Usually ships within 7 days. Voltage: 110-120 V or 220-240 V.
Manual
Manual (PDF)Pour X-Press Owner/Operator ManualPDF · 575.3 KB · 2026 editionDownload ManualView onlineTroubleshooting & videos
Choose a Size
Click a size to preview its photo and specs. Open its page to configure and buy.
Pour X-Press 3000 Enclosed Automated Wax Melting & Filling System
| Capacity | |
|---|---|
| Standard heating power | |
| Overall size (L x W x H) | |
| Lead time | Usually ships within 7 days |
From $13,995
Complete Automated Melting + Filling in One Enclosed Platform
Pour X-Press 3000 packages the PRIMO melter and AutoShot filling system into a fully enclosed mobile stainless-steel platform with integrated controls. It delivers the same core melt-to-fill workflow as PX2000 while presenting the equipment as a more finished production machine.
Choose PX3000 when automation, mobility and an enclosed equipment package are all part of the buying decision. The system is configured around batch size, fill range, hose reach, temperature, viscosity and available electrical service.
Best fit
professional candle and wax manufacturing floors that want an integrated automated system with enclosed stainless-steel presentation.
Practically Self Cleaning
Almost cleans itself.
Changing fragrance, color or product is close to automatic.
Close the ball valve and run the pump until the filling system is empty. A little material stays along the lining, which is normal. The system is fully heated and built from stainless steel and Teflon, so on your next batch you preheat, open the valve, run the new material through and discard the first few ounces. That is it.
Nothing comes apart. Not the pump, not the hose, not the filling head.
The melter cleans just as easily. Treat it like a high end stainless steel cooking pot: wipe it out with a cloth, or use soap and water for soap and food products. If something has burned on, a scouring pad takes care of it. Round tank, no corners to clean.
Customer Review
“The PX3000 has been fantastic. It improved our efficiency so much.”
Keith, Lazy River Products
Extended Information
PX3000 or PX2000
Both combine PRIMO melting with AutoShot automated filling. PX2000 uses an open-frame mobile platform; PX3000 encloses the system in stainless steel for a cleaner, more integrated machine presentation.
Configure Around the Actual Production Line
Select the PRIMO size from batch and daily demand, then match the AutoShot range to container sizes. Hose length, viscosity and electrical service complete the configuration.
Need help configuring the system?
Send your material, operating temperature, smallest and largest fill or transfer quantity, daily output, existing melter information and available electrical service for a production review.
See It in Action
Specifications
System Type
Integrated enclosed mobile melting + automated filling
Melting platform
PRIMO melter; size selected at order
Filling platform
AutoShot heated automated single-head filler
Fill range options
1/8 to 20 oz | 4 to 45 oz | 20 to 128 oz
Operating modes
Single measured shots or repeating on/off cycles
Standard process temperature
Up to 212°F / 100°C; configuration-dependent upgrades available
Cart
Fully enclosed stainless-steel mobile platform with built-in controls
Reference cart size
Current page lists 34 in L × 23 in W × 32 in H for a 150-lb melter model; larger melters require larger carts
Heated hose
Selectable length
Electrical / dimensions
Vary with selected PRIMO size, voltage and filling options
Final specifications depend on selected temperature range, viscosity, voltage, hose length and product options. Confirm the configured system requirements before installation.
Pour X-Press 3000 Enclosed Automated Wax Melting & Filling System questions and answers
How much does the Pour X-Press 3000 Enclosed Automated Wax Melting & Filling System cost and how fast does it ship?
The base price is $13,995. Options you select on the product page change the price live. Usually ships within 7 days.
How fast does this equipment ship?
Standard configurations ship on the lead time shown on this page, from Ronkonkoma, NY.
Can I buy online or request a formal quote?
Both. Configure the model and check out online, or request a quote and the factory team will confirm sizing, options and freight.
What warranty is included?
Limited Warranty (1 year on electrical, 3 years on metal parts, from delivery), with an optional Factory Protection Plan.
